10kgf Digital Durometer Automatic Testing Process And Loading Unloading System

Brand Name : JINHAIHU

Model Number : LHRSS-150

Certification : ISO 9001

Place of Origin : China

MOQ : 1 set

Payment Terms : L/C, D/A, D/P, T/T, MoneyGram, Western Union

Delivery Time : 7 -15 days

Packaging Details : Standard wooden case

Product name : Automatic Testing Process and Loading & Unloading system Digital Rockwell Hardness Durometer for Metal/Plastic Rockwell

Preliminary Testing force : 10kgf(98.07N)

Testing force : 60kgf(588N) 100kgf(980N) 150kgf(1471N)

Max Height of Specimen : 170mm

Distance of Indenter to outer wall : 165mm

Data output : Digital display

Overall Dimension (mm) : 520*240*720

Net weight : About 85kg

Contact Now

Automatic Testing Process and Loading & Unloading system Digital Rockwell Hardness Durometer for Metal/Plastic Rockwell


Functions & Features:
● Digital, multi-function LCD Touch Screen display
● Electric load; Automatic loading & unloading
● With printer for data output; PC connectivity
● Rockwell Scales: HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRH, HRK, HRL, HRM, HRR, HRP,HRS, HRV
● Conversion to Vickers, Brinell scales
● Shape correction settings for curved surfaces
● Automatic testing process without manual operating error;
● Meets or exceeds GB/T230.2, ISO 6508-2, ASTM E18 standards
● Optional Plastic Rockwell Accessories

Application:

● Ferrous and nonferrous metals, Hardened steel, tempered steel, annealed steel, sheet of various thicknesses, carbide materials, powder metallurgy materials, hardness and thermal spray coating.

● Industrial production, Inspection of product quality on processing technology.

Technical Parameters:

Model LHRSS-150
Indication of Hardness Value Large LCD Touch Screen display
Data output Built-in Printer, RS232
Duration time 0-60s
Carried Standard GB/T230.2,ISO6508-2,ASTME18
Preliminary Testing force 10kgf(98.07N)
Testing force 60kgf(588N) 100kgf(980N) 150kgf(1471N)
Rockwell Scale HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRH, HRK, HRL, HRM, HRR, HRP, HRS, HRV
Hardness measuring range HRA:20-95 HRB:10-100 HRC:20-70 HRD:40-77
HRF:60-100 HRG:30-94 HRH:80-100 HRK:40-100
HRL:50-115 HRM:50-115 HRR:50-115
Max Height of Specimen 170mm
Distance of Indenter to outer wall 165mm
Power supply AC220V+5%,50-60Hz
Overall Dimension (mm) 520*240*720
Net weight About 85Kg



Standard Accessories:

Name Quantity Name Quantity
Diamond Rockwell Indenter 1 1.5875mm Ball Indenter 1
Hardness block(HRC , HRB 1) 3 Large, Medium, “V” shaped Testing Table 3
Weights(A,B,C) 3 Plastic Dustproof cover 1
Paper for printing 1 RS232 Cable 1
Operation Manual 1 Product Certificate 1
